Description
Digitally Signed Firmware
Digitally signed firmware is a security feature that is designed to protect the integrity of the firmware on the HPE P04537-H21 3.2TB SAS-12GBPS SSD. This feature ensures that the firmware on the drive has been verified and authenticated by the manufacturer, and that it has not been tampered with or modified in any way.
When the drive is powered on, the firmware is verified and authenticated against the digital signature that is stored on the drive. If the firmware is found to be authentic, the drive will boot up and operate normally. However, if the firmware is found to be tampered with or modified in any way, the drive will not boot up and will indicate that the firmware is not authentic.
This feature is important because it helps to protect the drive from firmware-based attacks, such as those that can occur through malware or other malicious software. It also helps to ensure that the drive is operating with the most recent and secure firmware version, which can help to improve performance and security.
High-Speed Data Transfer
The HPE P04537-H21 3.2TB SAS-12GBPS SSD is a high-performance solid-state drive (SSD) designed for use in high-speed data transfer applications. The drive has a storage capacity of 3.2TB and uses SAS (Serial Attached SCSI) 12GBPS interface, which provides high data transfer speeds and low latency.
The SAS-12GBPS interface supports a maximum data transfer rate of 12 Gbps, which is significantly faster than traditional SAS 6GBPS interface. This makes the HPE P04537-H21 3.2TB SAS-12GBPS SSD ideal for applications that require fast data transfer and storage, such as data warehousing, high-performance computing, and video editing.
The drive’s large storage capacity also allows for the storage of large amounts of data, making it suitable for use in applications such as big data analytics, scientific research, and machine learning.
Additionally, the HPE P04537-H21 3.2TB SAS-12GBPS SSD features advanced data protection technology, including end-to-end data protection and power loss data protection, which ensures that data is not lost in the event of power failure or other disruptions. This makes the drive suitable for use in mission-critical applications where data integrity and availability are of the utmost importance.
Enhanced Reliability and Durability
The HPE P04537-H21 3.2TB SAS-12GBPS SSD is designed with enhanced reliability and durability to meet the needs of high-demand applications.
One of the key features of this SSD is its use of advanced data protection technology. This includes end-to-end data protection, which ensures that data is not lost in the event of power failure or other disruptions, and power loss data protection, which helps to protect data in case of unexpected power loss.
Additionally, the drive is built with high-quality components and undergoes rigorous testing to ensure that it can withstand the demands of high-performance applications. The drive is designed to operate in a wide range of temperatures and is built to resist vibrations and shock, making it suitable for use in environments where other drives may fail.
Furthermore, HPE P04537-H21 3.2TB SAS-12GBPS SSD is built with endurance and performance-enhancing techniques, such as advanced wear-levelling, over-provisioning, and data-recovery algorithms, which enable the drive to handle heavy workloads, such as large data transfers and high-intensity applications like big data analytics, machine learning, and virtualization.
Detail Description
- Manufacturer : HPE
- MPN : P04537-H21
- Type : Solid State Drive (SSD)
- SSD -Type : SAS-12GBPS
- Spare Part Number: P06582-001
- Model Number: MO003200JWTBU
- Assembly Number: P04174-004
- SKU : P04537-H21
Key Features
- Storage Capacity : 3.2TB
- Interface : Dual SAS-12GBPS
- Form Factor : 2.5 Inch
- NAND Flash Memory Type: Triple-level cell (TLC)
- Connectivity: Dual Port
- Plug Type: Hot Pluggable
- Carrier Type: Low Profile Converter (LPC)
- Workload Type: Mixed-Use
- Bundled with: HPE Low Profile Converter (LPC)
- Features: Digitally Signed Firmware
Performance
- Lifetime Writes: 17520
- Endurance DWPD (Drive Writes Per Day): 3
- Drive Transfer Rate: 1.2 GBps (external)
- MAX Seq. Reads Throughput (MiB/s): 1075
- MAX Seq. Writes Throughput (MiB/s): 1025
- Random Read Average Latency uSec (4KiB,Q1): 120
- Random Write Average Latency uSec (4KiB, Q1): 50
- Random Read IOPS (4KiB, Q=16): 125000
- Random Write IOPS (4KiB, Q=16): 93000
- MAX Random Read IOPS (4KiB): 185000@Q32
- MAX Random Write IOPS (4KiB): 93000@Q4
- 4KiB Random 70% Read / 30% Write, Queue 32 Performance (IOPS) VI-1: 120000
- 4KiB Random 50% Read / 50% Write, Queue 32 Performance (IOPS) VI-2: 107500
Power Consumption
- Power Idle Time: 4.22 Watt
- Power Random Read: 4.74 Watt
- Power Random Write: 4.74 Watt
- Power Sequential Read: 7.75 Watt
- Power Sequential Write: 9.50 Watt
- Power Random R/W: 4.74 Watt
Product Dimensions & Weight
- Height: 0.63 inch
- Width: 3.10 inch
- Depth: 5.45 inch
- Weight: 1.50 lbs
Compatibility
- HPE ProLiant DL Series: DL160 Gen9 (3.5 inch), DL160 Gen9 Base (3.5 inch), DL160 Gen9 Entry (3.5 inch), DL160 Gen9 Performance (3.5 inch), DL20 Gen9 Solution (2.5 inch), DL360 Gen10 (2.5 inch), DL360 Gen10 Base (2.5 inch), DL360 Gen10 Entry (2.5 inch), DL360 Gen10 High Performance (2.5 inch), DL360 Gen10 Low (2.5 inch), DL360 Gen10 Performance (2.5 inch), DL360 Gen10 Solution (2.5 inch), DL385 Gen10 (2.5 inch), DL385 Gen10 Base (2.5 inch), DL385 Gen10 Entry (2.5 inch), DL385 Gen10 High-Performance (2.5 inch), DL385 Gen10 Performance (2.5 inch), DL385 Gen10 Solution (2.5 inch), DL560 Gen10 (2.5 inch), DL560 Gen10 Base (2.5 inch), DL560 Gen10 Entry (2.5 inch), DL560 Gen10 Performance (2.5 inch), DL580 Gen10 (2.5 inch), DL580 Gen10 Base (2.5 inch), DL580 Gen10 Entry (2.5 inch), DL580 Gen10 Performance (2.5 inch), DL580 Gen9 (3.5 inch), DL580 Gen9 Base (3.5 inch), DL580 Gen9 Database (3.5 inch), DL580 Gen9 High Performance (3.5 inch), DL580 Gen9 SAP HANA Scale-up Base Configuration (3.5 inch) Servers
- HPE ProLiant ML Series: ML110 Gen10 Solution (2.5 inch), ML110 Gen9 (3.5 inch), ML110 Gen9 Base (3.5 inch), ML110 Gen9 Entry (3.5 inch), ML350 Gen10 (2.5 inch), ML350 Gen10 Base (2.5 inch), ML350 Gen10 Entry (2.5 inch), ML350 Gen10 Performance (2.5 inch), ML350 Gen10 Solution (2.5 inch), ML350 Gen10 Sub-Entry (2.5 inch) Servers
- HPE ProLiant XL Series: XL170r Gen9 (3.5 inch), XL450 Gen10 (2.5 inch) Servers
