Description
Advanced Switching Capabilities
The J9533A#ABA is a model number for a HP (Hewlett Packard) advanced switching switch that provides advanced switching capabilities for data centers and other network-intensive environments. This switch is designed to help organizations manage large amounts of data and improve network performance and security.
The HP 44pt PoE+ 1000+2pt 10GBE Sfp+ Slot+4 Switch Advanced Switching Capabilities has the following features:
- 44 ports PoE+: This switch has 44 ports that support Power over Ethernet Plus (PoE+), which allows the switch to provide power to devices such as access points and cameras.
- 1000+2pt 10GBE Sfp+ Slot: The switch has 1000Base-T Gigabit Ethernet and 2 SFP+ ports that support 10 Gigabit Ethernet for high-speed data transfer. The SFP+ slots allow for the use of SFP+ transceivers for added flexibility and network scalability.
- 4 additional switching slots: The switch has 4 additional slots that allow for the use of additional switches to further expand the network.
- Advanced switching capabilities: The switch has advanced switching capabilities that include support for advanced network protocols, such as VLANs and Quality of Service (QoS), to help manage network traffic and improve network performance and security.
Network Security
The J9533A#ABA HP 44pt PoE+ 1000+2pt 10GBE Sfp+ Slot+4 Switch is a network switch designed for use in small to medium-sized businesses. The switch provides 44 Power over Ethernet (PoE) ports and 2 Gigabit Ethernet ports for connecting devices, as well as 4 10 Gigabit Ethernet (10GBE) SFP+ slots for high-speed network connections.
The switch also offers network security features such as VLANs, access control lists (ACLs), and security protocols like 802.1X and IP Source Guard. This helps to prevent unauthorized access to the network and protect against network attacks.
Easy Management and Configuration
The J9533A#ABA HP 44pt PoE+ 1000+2pt 10GBE Sfp+ Slot+4 Switch is a high-performance network switch designed for enterprise-level networks. It offers a total of 44 Power over Ethernet (PoE+) ports, 1000 Mbps Ethernet ports, and two 10 Gbps SFP+ slots for high-speed connectivity. The switch also includes four additional Gigabit Ethernet ports for flexible network expansion.
The switch is equipped with advanced management and configuration features, making it easy for network administrators to manage and configure their network. The switch is equipped with a user-friendly web interface that allows administrators to access and configure the switch from anywhere on the network. Additionally, the switch can be managed through SNMP and other management protocols, making it possible to integrate the switch into a larger network management framework.
The J9533A#ABA HP 44pt PoE+ 1000+2pt 10GBE Sfp+ Slot+4 Switch is designed to provide reliable and secure connectivity, making it an ideal choice for enterprise-level networks. With its high-speed connectivity, advanced management features, and easy configuration options, this switch is sure to meet the demands of modern networks.
General Information about the HPE J9533A#ABA
- Manufacturer: HP
- Model Number or SKU#J9533A#ABA
- Type: Networking
- Switch-Type: 44 Ports
Technical Information
- Enclosure Type : Rack-Mountable – 4u
- Ports : 44 X 10/100/1000 + 2 X Sfp+
- Power Over Ethernet (Poe) : Yes
- Performance : Switching Capacity : 379.2 Gbps
- Mac Address Table Size : 64k Entries
- Routing Protocol : Rip-1, Rip-2, Ospfv2, Static Ip Routing, Igmpv3, Ospfv3, Static Ipv6 Routing
- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Snmp 2c, Http
- Encryption Algorithm : Ssl
- Authentication Method : Secure Shell (Ssh), Radius, Tacacs+, Secure Shell V.2 (Ssh2)
- Processor : 1 X Freescale Powerpc 8540 : 666 Mhz
- Ram : 256 Mb – Ddr Sdram
- Flash Memory : 128 Mb (Max)
Expansion / Connectivity
- Interfaces : 44 X 10base-T/100base-Tx/1000base-T – Rj-45 – Poe 1 X Rs-232c – Management 2 X Sfp+
- Expansion Slots Total (Free) : 6 ( 4 ) X Expansion Slot 1 ( 1 ) X Compactflash Card
- Installed Modules Qty (Max) : 2 (Installed) / 6 (Max)
Dimensions & Weight
- Width: 17.5 inch
- Depth : 17.8 inch
- Height : 6.9 inch
- Weight : 46 lbs
Power
- Power Device : Power Supply – Hot-Plug – Plug-In Module
- Voltage Required : Ac 120/230 V ( 50/60 Hz )
- Routing Protocol
