Description
Introduction to X2692 Dell
The X2692 Dell Nvidia Quadro FX3000 is a high-end 3D graphics card that was originally released in 2004. It is designed for professional use in applications such as computer-aided design (CAD), digital content creation (DCC), and scientific visualization. The card features 256MB of GDDR3 memory, an AGP 8X interface, and dual DVI connectivity, which enables users to connect two digital displays simultaneously.
The Quadro FX3000 was one of the top-performing graphics cards of its time and is still capable of running many demanding 3D applications. It is also known for its stability and reliability, making it a popular choice for professionals in various fields.
The X2692 is specifically designed for use in Dell workstations, but it is also compatible with other systems that have an AGP 8X slot. Overall, the X2692 Dell Nvidia Quadro FX3000 is a powerful graphics card that offers advanced features and capabilities for professional users who require high-end 3D graphics performance.
Specifications of the X2692 Dell Nvidia Quadro FX3000
Sure, here are some more details about the specifications of the X2692 Dell Nvidia Quadro FX3000 graphics card:
- Graphics Processor Unit (GPU): The Quadro FX3000 features the NV35 GPU with 256MB of GDDR3 memory. The GPU has a clock speed of 425MHz and a memory clock speed of 500MHz.
- Interface: The card uses an AGP 8X interface, which allows it to achieve faster data transfer rates compared to earlier AGP standards.
- Dual DVI Connectivity: The X2692 supports two digital displays simultaneously via dual DVI connectivity. The card can also output to standard VGA displays with the use of an adapter.
- 3D Graphics Performance: The Quadro FX3000 is designed for high-end 3D graphics applications and can deliver up to 6.4GB/s of memory bandwidth. It also features advanced shader technology, which enables it to render complex scenes and models with high precision.
- Compatibility: The X2692 Dell Nvidia Quadro FX3000 is compatible with a range of operating systems, including Windows XP, Windows 2000, and Linux.
- Power Requirements: The card requires a minimum power supply of 300 watts and features a single six-pin power connector.
AGP 8X Interface
AGP (Accelerated Graphics Port) is an interface standard that was developed in the late 1990s for connecting graphics cards to a computer’s motherboard. AGP 8X is the fastest and most advanced version of this interface, and it was introduced in 2002 as an improvement over the earlier AGP 4X standard.
The AGP 8X interface allows for faster data transfer rates between the graphics card and the motherboard, which translates to better performance for graphics-intensive applications. The AGP 8X interface supports a peak bandwidth of 2.1 GB/s, which is more than twice the maximum bandwidth supported by the AGP 4X interface.
To take advantage of the AGP 8X interface, both the graphics card and the motherboard must support this standard. If the motherboard does not support AGP 8X, then the graphics card will not perform at its maximum potential. Similarly, if the graphics card does not support AGP 8X, it will not be able to take advantage of the increased bandwidth offered by the motherboard.
PROCESSOR :
- Graphic Processor : Nvidia Quadro Fx3000
- Gpu Clock Speed : 325 Mhz
- Ramdac Speed : 400 Mhz
Key Features:
- Card Interface : Agp8x
- Compatibility : Pc
Memory:
- Installed Memory : 256MB
- Memory Tech : DDR Sdram
- Installed Memory / Technology : 256MB (DDR Sdram)
