Product Overview of the Cisco N5K-M1600 6 Ports Expansion Module
The Cisco N5K-M1600 1000 Series features 6 ports, each supporting 10 GBPS data transfer rates. These ports utilize Small Form-Factor Pluggable Plus-SFP+ technology, which ensures compatibility and flexibility in various networking setups. Additionally, the device incorporates 6 x Small Form-Factor Pluggable Plus (SFP+) expansion slots, allowing for scalability and expansion based on the network’s evolving needs.
Key Features for 10 Gigabit Ethernet Expansion Module10 Gigabytes Per Second (GBPS)
The Cisco N5K-M1600 1000 Series switch offers 6 ports, each capable of transmitting data at a speed of 10 GBPS. This high-speed connectivity is essential for handling large volumes of data in modern network environments.
6 x Small Form-Factor Pluggable Plus (SFP+) Expansion Slots
SFP+ expansion slots allow for flexible connectivity options, enabling the switch to be adapted to various networking needs. These slots support Small Form-Factor Pluggable Plus (SFP+) modules, which are interchangeable optical or copper transceiver modules used for connecting network devices over different types of media.
Gigabit Ethernet Small form-factor pluggable (SFP) Expansion Module
The Gigabit Ethernet Small form-factor pluggable (SFP) expansion module enhances the switch’s capabilities by providing additional Gigabit Ethernet connectivity options. This allows for the integration of devices that require Gigabit Ethernet speeds into the network.
Importance of High-Speed Connectivity
In today’s digital landscape, where the volume of data generated and transmitted across networks is constantly increasing, high-speed connectivity is crucial. The Cisco N5K-M1600 1000 Series switch addresses this need by offering 10 GBPS ports, enabling swift data transfer and reducing latency within the network.
Flexibility and Scalability
The inclusion of 6 x SFP+ expansion slots enhances the switch’s flexibility and scalability. These slots allow for the integration of additional networking modules or connectivity options as per the evolving requirements of the network infrastructure. Whether it’s fiber-optic connections for long-distance transmission or copper cables for shorter distances, the SFP+ slots offer versatility.
Versatile Connectivity Options
The Gigabit Ethernet Small form-factor pluggable (SFP) Expansion Module further expands the connectivity options of the Cisco N5K-M1600 1000 Series switch. Gigabit Ethernet is a standard for high-speed wired networking and is widely used in various applications, including data centers, enterprise networks, and telecommunications.
Performance Benchmarks of the 10 GBPS Expansion Module
The N5K-M1600 Cisco 1000 Series 6 Ports 10 GBPS Expansion Module is a high-performance network expansion module designed to be used with the Cisco Nexus 5000 Series Switches. This module provides six additional 10 Gigabit Ethernet ports that can be used for various network connectivity requirements.
When it comes to performance benchmarks, the N5K-M1600 expansion module offers impressive numbers. Here are some of the key performance metrics of this module:
- Data Transfer Rate: The N5K-M1600 expansion module supports a data transfer rate of up to 10 Gigabits per second (Gbps) per port. This means that each port can transfer data at a maximum speed of 10 Gbps, providing fast and reliable network connectivity.
- Latency: The N5K-M1600 expansion module has low latency, which means that data can be transmitted quickly between devices. The latency of this module is typically around 2-3 microseconds.
- Throughput: The N5K-M1600 expansion module has a high throughput, which means that it can handle large amounts of data traffic without slowing down. The module has a maximum theoretical throughput of 60 Gbps, which is the combined throughput of all six ports.
- Jumbo Frames: The N5K-M1600 expansion module supports jumbo frames, which are larger than standard Ethernet frames. This can help to improve network performance by reducing the number of frames that need to be transmitted.
Power Consumption and Heat Dissipation
The N5K-M1600 is a Cisco Nexus 5000 Series switch module that provides 6 ports of 10 Gigabit Ethernet connectivity. In terms of power consumption, the N5K-M1600 has a maximum power draw of 210 Watts. This means that when all six ports are being used at full capacity, the module will consume up to 210 Watts of power.
The heat dissipation of the N5K-M1600 depends on the power consumed by the module. As mentioned above, the maximum power consumption of the module is 210 Watts. Therefore, the heat dissipation of the module can be estimated using the formula: Heat dissipation = Power consumption x Efficiency.
The efficiency of the N5K-M1600 is not explicitly stated in its documentation, but it is typically around 70-80% for network equipment. Assuming an efficiency of 75%, the heat dissipation of the N5K-M1600 can be estimated as follows:
Heat dissipation = 210 Watts x 0.75 = 157.5 Watts
This means that the module will dissipate approximately 157.5 Watts of heat when all six ports are being used at full capacity. It is important to ensure that the switch chassis and ventilation system are designed to handle this level of heat dissipation to prevent overheating and potential equipment failure.
Use CasesData Centers
In data center environments, where rapid data processing and transfer are paramount, switches like the Cisco N5K-M1600 1000 Series play a critical role. The high-speed ports and flexible connectivity options make it well-suited for handling the demands of modern data centers, including virtualization, cloud computing, and big data analytics.
Enterprise Networks
Large enterprises often require robust networking infrastructure to support their day-to-day operations. The Cisco N5K-M1600 1000 Series switch can serve as a backbone for enterprise networks, providing reliable connectivity and high-performance data transmission across various departments and locations.
Telecommunications
In telecommunications networks, where reliability and speed are of utmost importance, switches like the Cisco N5K-M1600 1000 Series ensure seamless communication between different nodes and devices. Whether it’s delivering high-definition media content or facilitating real-time voice and video communication, the switch plays a vital role in maintaining network efficiency.
Quality of Service Capabilities
The N5K-M1600 is a Cisco Nexus 5000 Series switch module that provides six ports of 10 Gigabit Ethernet connectivity with a maximum data transfer rate of 10 Gbps. It is designed to expand the capabilities of the Nexus 5000 Series switches, which are used in data center environments to provide high-performance networking and storage connectivity.
One of the key features of the N5K-M1600 module is its Quality of Service (QoS) capabilities. QoS refers to the ability of a network device to prioritize certain types of traffic over others, ensuring that critical applications and services receive the necessary bandwidth and network resources to function properly.
The N5K-M1600 module supports a range of QoS features, including:
- Traffic Classification: The module can classify traffic based on a variety of parameters, such as the source and destination IP addresses, protocol type, application type, and port number. This enables the module to identify and prioritize different types of traffic based on their importance.
- Priority Queuing: The module supports up to eight priority queues, which can be used to prioritize traffic based on its classification. Each queue is assigned a priority level, and traffic is serviced in order of its priority level. This helps to ensure that high-priority traffic is serviced before lower-priority traffic.
- Bandwidth Allocation: The module can allocate a specific amount of bandwidth to each priority queue, ensuring that high-priority traffic receives the necessary bandwidth to function properly. This can help to prevent congestion on the network and ensure that critical applications and services receive the necessary network resources.
- Congestion Management: The module supports a range of congestion management techniques, such as Weighted Random Early Detection (WRED) and tail drop. These techniques are used to prevent network congestion and ensure that traffic is serviced in an orderly manner.
- Traffic Policing: The module can police traffic to ensure that it conforms to pre-defined policies. This can be used to limit the amount of bandwidth that certain types of traffic can consume, ensuring that other types of traffic are not adversely affected.
General Information of the Cisco N5K-M1600 Expansion Module
- Manufacturer: Cisco
- Part Number or SKU# N5K-M1600
- Product Type: Expansion Module
Technical Information
- Application/Usage: Data Networking, Optical Network
- Total Number of Ports: 6
I/O Expansions
- Expansion Slots: 6 x SFP+
Outline, the Cisco N5K-M1600 1000 Series switch offers a potent combination of high-speed connectivity, flexibility, and scalability, making it an ideal choice for modern network infrastructures. With its 10 GBPS ports, SFP+ expansion slots, and Gigabit Ethernet capabilities, it caters to the diverse needs of data centers, enterprise networks, and telecommunications environments. As technology continues to evolve, switches like the Cisco N5K-M1600 1000 Series will remain at the forefront of network innovation, enabling seamless connectivity and data transmission in an increasingly interconnected world.
